Product Specifications
| Product Collection | Intel NUC Kit with Intel Celeron Processors |
|---|---|
| Code Name | Products formerly Chaco Canyon |
| Board Form Factor | 3.5″ SBC (146mm x 101.6mm) |
| Internal Drive Form Factor | M.2 SSD |
| Embedded Storage | 64 GB |
| DC Input Voltage Supported | 12V – 24V |
| Processor Included | Intel Celeron Processor N3350 (2M Cache, up to 2.4 GHz) |
| Embedded Options Available | No |
| Included Storage | 64GB eMMC |
| Included Memory | 4GB LPDDR3 (dual-channel, soldered-down) |
| ECC Memory Supported | No |
| Processor Graphics | Intel HD Graphics 500 |
| Graphics Output | HDMI 2.0, HDMI 1.4, 4-lane eDP 1.4 |
| # of Displays Supported | 2 |
| PCI Express Revision | Gen 2 |
| M.2 Card Slot (wireless) | 22×30 slot (key E) |
| M.2 Card Slot (storage) | 22×80 slot (key M; NVMe/SATA) |
| # of USB Ports | 4 |
| USB Configuration | 1x front and 1x rear USB 3.0; 2x rear USB 2.0; 1x USB 3.0 and 2x USB 2.0 via internal headers |
| Serial Port via Internal Header | Yes |
| Audio (back channel + front channel) | 1/8″ line out |
| Integrated LAN | Intel i211-AT (10/100/1000 Mbps) |
| Integrated Wireless | Intel Dual Band Wireless-AC 3168 |
| Integrated Bluetooth | Yes |
| Additional Headers | Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2×2 power connector |
| Chassis Dimensions | 154 x 108 x 32 mm |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel vPro Platform Eligibility | No |
| TPM | No |
| Intel HD Audio Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Platform Trust Technology (Intel PTT) | Yes |
| Intel AES New Instructions | Yes |
| Intel Trusted Execution Technology | No |
