Product Description
- Digital class D linkable monoblock amplifier
- Wired Remote Control Included
- 4000W RMS @ 1 Ohm
- 2000W RMS @ 2 Ohms
- MOSFET PWM power supply
- Double sided through hole epoxy PCB
- Stable into 1 Ohm and 2 Ohms parallel amplifier connection availability
- 24db/oct variable crossover
- Variable subsonic filter
- Variable bass boost
- Variable low pass filter
- Variable phase shift
- Efficiency: 86%@4 ohms at 100Hz
- Multi-way protection circuitry (Thermal / over current / speaker short / speaker DC protection)
- RCA line input
- Tested voltage & THD: 14.4V & less than 1% THD
- Operating voltage: DC10v – 15V power input
- Signal to noise ratio: >95db
- Low pass frequency crossover: 40Hz – 200Hz
- Subsonic filter: 0Hz – 50Hz
- Bass boost @ 45Hz: 0 – 12db
- Phase shift control: 0 – 180 degree
- Frequency response: 10Hz – 200Hz (-3db)
- T.H.D @ 4 Ohms: <1%
- Efficiency @ 4 Ohms: 86%
- Fuse rating: 150A (external type fuse)
- Input sensitivity: 150Mv-5v (+/-5%)
