| Sensor | 1/3", 4 megapixel, progressive scan CMOS |
|---|
| Lens | 2.8 mm@F2.0 |
|---|
| Angle of View (H) | 101.8deg |
|---|
| Shutter | Auto/Manual, 1/6~1/100000 s |
|---|
| Min. Illumination | Colour: 0.02 Lux (F2.0, AGC ON)
0 Lux with IR |
|---|
| Day/Night | IR-cut filter with auto switch (ICR) |
|---|
| S/N | 55 dB |
|---|
| WDR | 120 dB |
|---|
| Max. Resolution | 2592 x 1520 |
|---|
| Video Compression | H.265, H.264, MJPEG |
|---|
| Frame Rate | 4MP (2592×1520): Max. 20 fps, 4MP (2560×1440): Max. 25 fps
3MP (2048×1520): Max. 30 fps, 1080P (1920×1080): Max. 30 fps |
|---|
| Video Streaming | Triple |
|---|
| 9:16 Corridor Mode | Supported |
|---|
| ROI | Supported |
|---|
| Evaluative Metering | Supported |
|---|
| OSD | Up to 8 OSDs |
|---|
| Privacy Mask | Up to 8 areas |
|---|
| Behavior Detection | Intrusion, crossing line, motion detection |
|---|
| Exception Detection | Audio detection |
|---|
| Intelligent Identification | Face detection, Defocus, Scene Change |
|---|
| Statistical Analysis | People counting |
|---|
| Audio Compression | G.711 |
|---|
| Two-way audio | Supported |
|---|
| Edge Storage | Micro SD, up to 128 GB |
|---|
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x |
|---|
| Compatible Integration | ONVIF, API |
|---|
| Audio I/O | Input: impedance 35 k?, amplitude 2 V [p-p]
Output: impedance 600 ?, amplitude 2 V [p-p] |
|---|
| Alarm I/O | 01-Jan |
|---|
| Network | 10M/100M Base-TX Ethernet |
|---|
| Power | 12 V DC, or PoE (IEEE802.3 af)
Power consumption: Max 5.5W |
|---|
| Dimensions (Ø x H) | Ø108.5 x 81 mm (Ø4.28" x 3.2") |
|---|
| Weight | 0.45 kg (0.99 lb) |
|---|
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ? 95% RH(non-condensing) |
|---|
| Ingress Protection | IP67 |
|---|
| Vandal Resistant | IK10 |
|---|
| Weight | 0.06 kg |
|---|
| Dimensions | 14.000000 × 14.000000 × 14.000000 cm |
|---|
|
