| Item | IPC322SB-DF28K-I0 |
|---|
| Sensor | 1/2.8", 2.0 megapixel, progressive scan, CMOS |
|---|
| Lens | 2.8mm@F1.6 |
|---|
| Angle of View (H) | 106.7° |
|---|
| Angle of View (V) | 57.1° |
|---|
| Angle of View (O) | 115.7° |
|---|
| Adjustment angle | Pan: 3° ~ 360° |
|---|
| Shutter | Auto/Manual, 1 ~ 1/100000s |
|---|
| Minimum Illumination | Colour:0.001 Lux (F1.6, AGC ON)
0Lux with IR |
|---|
| Day/Night | IR-cut filter with auto switch (ICR) |
|---|
| S/N | 52dB |
|---|
| IR Range | Up to 30m (98ft) IR range |
|---|
| Wavelength | 850nm |
|---|
| IR On/Off Control | Auto/Manual |
|---|
| Defog | Digital Defog |
|---|
| WDR | 120dB |
|---|
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
|---|
| H.264 code profile | Baseline profile, Main profile, High profile |
|---|
| Frame Rate | Main Stream: 2MP (1920*1080), Max 30fps, 720P (1280*720), Max 30fps
Sub Stream: 720P (1280*720), Max 30fps, D1 (720*576), Max 30fps, 640*360, Max 30fps, 2CIF(704*288), Max 30fps, CIF(352*288), Max 30fps
Third Stream: D1 (720*576), Max 30fps, 640*360, Max 30fps, 2CIF(704*288), Max 30fps, CIF(352*288), Max 30fps |
|---|
| Video Bit Rate | 128 Kbps~16 Mbps |
|---|
| 9:16 Corridor Mode | Supported |
|---|
| OSD | Up to 8 OSDs |
|---|
| Privacy Mask | Up to 4 areas |
|---|
| ROI | Up to 8 areas |
|---|
| Motion Detection | Up to 4 areas |
|---|
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
|---|
| Digital Noise Reduction | 2D/3D DNR |
|---|
| Smart IR | Supported |
|---|
| Flip | Normal / Vertical / Horizontal / 180° / 90°Clockwise / 90°Anti-clockwise |
|---|
| Dewarping | N/A |
|---|
| HLC | Supported |
|---|
| BLC | Supported |
|---|
| Audio Compression | G.711 |
|---|
| Two-way Audio | Supported |
|---|
| Suppression | Supported |
|---|
| Sampling Rate | 8KHZ |
|---|
| Edge Storage | Micro SD, up to 256GB |
|---|
| Network Storage | ANR, NAS(NFS) |
|---|
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
|---|
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
|---|
| Client | EZStation
EZView
EZLive |
|---|
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|---|
| Audio I/O | 1 Input: impedance 35k?, amplitude 2V [p-p]
1 Output: impedance 600?, amplitude 2V [p-p] |
|---|
| Alarm I/O | 01-Jan |
|---|
| Network | 1 RJ45 10M/100M Base-TX Ethernet"3" style="bord |
|---|
| Certifications | CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
|---|
| Power | DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 5.0W |
|---|
| Dimensions (Ø x H) | Ø108.7 x 81.1mm (Ø4.3" x 3.2") |
|---|
| Net Weight | 0.42kg (0.93lb) |
|---|
| Material | Metal + Plastic |
|---|
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
|---|
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
|---|
| Surge Protection | 2KV |
|---|
| Ingress Protection | IP67 |
|---|
| Vandal Resistant | IK10 |
|---|
| Reset Button | Supported |
|---|
|
