WAN |
1 x WAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX crossover
|
---|
LAN |
4 x LAN ports (can be configured as secondary WAN ports), 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX crossover
|
---|
Routing |
Static routes, Dynamic routes (planned)
|
---|
Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP (planned), SMTP, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP (planned), MQTT (planned), Wake on LAN (WOL) (planned)
|
---|
VoIP passthrough support |
H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
|
---|
Connection monitoring |
Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
|
---|
DHCP |
Static and dynamic IP allocation, DHCP Relay
|
---|
QoS / Smart Queue Management (SQM) (planned) |
Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
|
---|
DDNS (planned) |
Supported 25 service providers, others can be configured manually
|
---|
Network backup |
Wired WAN options, each of which can be used as an automatic Failover
|
---|
Load balancing |
Balance Internet traffic over multiple WAN connections
|
---|
SSHFS |
Possibility to mount remote file system via SSH protocol
|
---|
Authentication |
Pre-shared key, digital certificates, X.509 certificates
|
---|
Firewall |
Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T
|
---|
Attack prevention |
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, flags, FIN scan attacks)
|
---|
VLAN |
Port and tag based VLAN separation
|
---|
WEB filter (planned) |
Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
|
---|
Access control |
Flexible access control of TCP, UDP, ICMP packets, MAC address filter
|
---|
OpenVPN |
Multiple clients and a server can run simultaneously, 12 encryption methods
|
---|
OpenVPN Encryption |
DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
|
---|
IPSec |
IKEv1, IKEv2, with 5 encryption methods for IPsec (DES, 3DES, AES128, AES192, AES256)
|
---|
GRE |
GRE tunnel
|
---|
PPTP, L2TP |
Client/Server instances can run simultaneously, L2TPv3 support (planned)
|
---|
Stunnel (planned) |
Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program's code
|
---|
DMVPN (planned) |
Method of building scalable IPsec VPNs
|
---|
SSTP (planned) |
SSTP client instance support
|
---|
ZeroTier |
ZeroTier VPN client support
|
---|
WireGuard |
WireGuard VPN client and server support
|
---|
ID filtering |
Respond to one ID in range [1, 255] or any
|
---|
Allow remote access |
Allow access through WAN
|
---|
Custom registers |
MODBUS TCP custom register block, which allows to read/write to a file inside the router, and can be used to extend MODBUS TCP slave functionality
|
---|
Supported functions |
01, 02, 03, 04, 05, 06, 15, 16
|
---|
Supported data formats |
8 bit: INT, UINT, 16 bit: INT, UINT (MSB or LSB first), 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII
|
---|
Gateway |
Allows sending commands and receiving data from MODBUS Master trough MQTT broker
|
---|
Protocols |
HTTP(S), MQTT, Azure MQTT, Kinesis
|
---|
SSH |
SSH (v1, v2)
|
---|
TR-069 |
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
|
---|
MQTT (planned) |
MQTT Broker, MQTT publisher
|
---|
SNMP (planned) |
SNMP (v1, v2, v3), SNMP trap
|
---|
JSON-RPC |
Management API over HTTP/HTTPS
|
---|
MODBUS (planned) |
MODBUS TCP status/control
|
---|
CPU |
QCA9531, MIPS 24kc, 650 MHz
|
---|
RAM |
64 MB, DDR2
|
---|
FLASH storage |
16 MB, SPI Flash
|
---|
WEB UI |
Update FW from file, check FW on server, configuration profiles, configuration backup
|
---|
FOTA |
Update FW/configuration from server
|
---|
RMS |
Update FW/configuration for multiple devices at once
|
---|
Keep settings |
Update FW without losing current configuration
|
---|
Data rate |
USB 2.0
|
---|
Applications |
Samba share (planned), USB-to-serial (planned)
|
---|
External devices |
Possibility to connect external HDD, flash drive, printer (planned)
|
---|
Storage formats |
FAT, FAT32, NTFS
|
---|
Configurable I/O |
2 x Configurable digital Inputs/Outputs. Digital input 0 – 6 V detected as logic low, 8 – 30 V detected as logic high. Open collector output, max output 30 V, 300 mA
|
---|
Events |
Email, RMS
|
---|
I/O juggler |
Allows to set certain I/O conditions to initiate event
|
---|
Connector |
4 pin industrial DC power socket
|
---|
Input voltage range |
7 – 30 VDC, reverse polarity protection, voltage surge/transient protection
|
---|
PoE (passive) |
Passive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
|
---|
Power consumption |
Idle: 1.3 W, Max: 3 W
|
---|
Ethernet |
5 x RJ45 ports, 10/100 Mbps
|
---|
I/Os |
2 x Configurable digital Inputs/Outputs on 4 pin power connector
|
---|
Status LEDs |
5 x ETH status, 1 x Power
|
---|
Power |
1 x 4 pin DC connector
|
---|
USB |
1 x USB A port for external devices
|
---|
Reset |
Reboot/User default reset/Factory reset button
|
---|
Casing material |
Aluminium housing with DIN rail mounting option
|
---|
Dimensions (W x H x D) |
100 x 30 x 85 mm
|
---|
Weight |
229 g
|
---|
Mounting options |
DIN rail, flat surface placement
|
---|
Operating temperature |
-40 C to 75 C
|
---|
Operating humidity |
10 % to 90 % non-condensing
|
---|
|
