Tazer 1/10 6P BL Mot 4000Kv SCT
R1,110.00 incl. VAT
Only 2 left in stock
Product Description
Key Features
- 6-pole design for high power and superior efficiency
- Improved rotor and stator design for elevated power output and enhanced efficiency
- Comes pre-wired for easy installation with bullet plugs
- Ball bearing construction provides low drag and long life
- Designed to work with most 1/10-scale sensorless brushless ESCs
Overview
The 6-pole brushless motors are available with different Kv versions.
Product Specifications
| Adjustable Timing | No |
| Connector Type | 3.5mm Bullet |
| Efficiency | 90% |
| Idle Current (Io) | 3.5+/-0.5A @ 7.2V |
| Input Voltage | 4.5-12.6V |
| Maximum Burst Current | 130A |
| Motor Design | Inrunner |
| Motor Type | Brushless |
| Number of Poles | 6 |
| Outer Diameter | 1.41 in (35.8mm) |
| Output | 250w @7.2V |
| Product Length | 2.05″ (52 mm) |
| Product Weight | 6.9oz (198g) |
| Recommended Speed Control | 45A |
| RPM/Volt (Kv) | 4000Kv |
| Shaft Diameter | 1/8 in (3.175mm) |
| Shaft Length | 0.67 in (17mm) |
| Size | 540 |
| Wire Gauge | 10 AWG |
