Product Description
| Hardware Specifications | |
| Copper Ports | 48 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| SFP/mini-GBIC Slots | 4 100/1000BASE-X SFP interfaces, |
| Supports 100/1000Mbps dual mode and DDM | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 104Gbps / non-blocking |
| Switch Throughput@64bytes | 77.38Mpps @64bytes |
| Address Table | 16K entries |
| Shared Data Buffer | 12Mbit SRAM packet buffer |
| Flow Control | IEEE 802.3x pause frame for full-duplex |
| Back pressure for half-duplex | |
| Jumbo Frame | 10K bytes |
| Reset Button | < 5 sec: System reboot |
| > 5 sec: Factory default | |
| LED | System: |
| PWR(Power) (Green) | |
| SYS(System) (Green) | |
| 10/100/1000T RJ45 Interfaces (Port 1 to Port 48): | |
| 1000Mbps (Orange), LNK/ACT (Green) | |
| 10/100Mbps (None), LNK/ACT (Green) | |
| 100/1000Mbps SFP Interfaces (Port 49 to Port 52): | |
| 1000Mbps, LNK/ACT (Green) | |
| 100Mbps, LNK/ACT (Orange) | |
| Thermal Fan | Fanless design |
| Power Requirements | AC 100~240V, 50/60Hz, auto-sensing. |
| ESD Protection | 6KV DC |
| Power Consumption / Dissipation | 34 watts / 116 BTU |
| Dimensions (W x D x H) | 440 x 300 x 44.5 mm, 1U height |
| Weight | 3.7 kg |
| Enclosure | Metal |
| Layer 2 Functions | |
| Port Mirroring | TX / RX / Both |
| Many-to-1 monitor | |
| VLAN | 802.1Q tagged-based VLAN |
| Up to 256 VLAN groups, out of 4094 VLAN IDs | |
| 802.1ad Q-in-Q tunneling (VLAN stacking) | |
| Voice VLAN | |
| Protocol VLAN | |
| Private VLAN (Protected port) | |
| GVRP | |
| Management VLAN | |
| Link Aggregation | IEEE 802.3ad LACP and static trunk |
| Supports 8 trunk groups with each having 8 ports | |
| Spanning Tree Protocol | STP, IEEE 802.1D Spanning Tree Protocol |
| RSTP, IEEE 802.1w Rapid Spanning Tree Protocol | |
| MSTP, IEEE 802.1s Multiple Spanning Tree Protocol | |
| STP BPDU Guard, BPDU Filtering and BPDU Forwarding | |
| IGMP Snooping | IGMP (v2/v3) snooping |
| IGMP querier | |
| Up to 256 multicast groups | |
| MLD Snooping | IPv6 MLD (v1 / v2) snooping, up to 256 multicast groups |
| Access Control List | IPv4/IPv6 IP-based ACL / MAC-based ACL |
| IPv4/IPv6 IP-based ACE / MAC-based ACE | |
| QoS | 8 mapping ID to 8 level priority queues |
| Port number | |
| 802.1p priority | |
| DSCP / IP precedence of IPv4 / IPv6 packets | |
| Traffic classification based, strict priority and WRR | |
| Ingress / Egress Rate Limit per port bandwidth control | |
| Security | IEEE 802.1X port-based authentication |
| Built-in RADIUS client to co-operate with RADIUS server | |
| RADIUS / TACACS+ authentication | |
| IP-MAC port binding | |
| MAC filtering | |
| Static MAC address | |
| DHCP snooping and DHCP Option82 | |
| STP BPDU guard, BPDU filtering and BPDU forwarding | |
| DoS attack prevention | |
| ARP inspection | |
| IP source guard | |
| Storm control support | |
| Broadcast / unknown unicast / unknown multicast | |
| Management Functions | |
| Basic Management Interfaces | Web browser / Telnet / SNMP v1, v2c, v3 |
| Firmware upgrade via HTTP / TFTP protocol through Ethernet network | |
| Configuration upload / download through HTTP / TFTP | |
| Remote / Local Syslog | |
| System log | |
| LLDP protocol | |
| SNTP | |
| PLANET Smart Discovery Utility | |
| Secure Management Interfaces | SSH, SSL, SNMPv3 |
| SNMP MIBs | RFC 3635 Ethernet-like MIB |
| RFC 2863 Interface Group MIB | |
| RFC 2819 RMON (1, 2, 3, 9) | |
| RFC 1493 Bridge MIB | |
| Standards Conformance | |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX / 100BASE-FX | |
| IEEE 802.3z Gigabit SX/LX | |
| IEEE 802.3ab Gigabit 1000BASE-T | |
| IEEE 802.3x flow control and back pressure | |
| IEEE 802.3ad port trunk with LACP | |
| IEEE 802.1D Spanning Tree Protocol | |
| IEEE 802.1w Rapid Spanning Tree Protocol | |
| IEEE 802.1s Multiple Spanning Tree Protocol | |
| IEEE 802.1p Class of Service | |
| IEEE 802.1Q VLAN tagging | |
| IEEE 802.1X Port Authentication Network Control | |
| IEEE 802.1ab LLDP | |
| RFC 768 UDP | |
| RFC 793 TFTP | |
| RFC 791 IP | |
| RFC 792 ICMP | |
| RFC 2068 HTTP | |
| RFC 1112 IGMP version 1 | |
| RFC 2236 IGMP version 2 | |
| RFC 3376 IGMP version 3 | |
| RFC 2710 MLD version 1 | |
| RFC 3810 MLD version 2 | |
| Environment | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Storage | Temperature: -20 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Weight | 4 kg |
|---|---|
| Dimensions | 50 × 40 × 50 cm |
