OWC Mercury Elite Pro USB3.1|USB-C 2.5″ 0TB
R1,899.99 incl. VAT
Get the most performance for your portable RAID setup with the OWC Mercury Elite Pro Dual Mini 2.5″ USB3.1|USB-C Enclosure. It features support for 2.5″ SATA 6Gb/s drives, RAID 0 and RAID 1 support, dual drive support and comes in an alluminum chassis.
Out of stock
The OWC Mercury Elite Pro Dual mini is the latest high-performance portable RAID from OWC. Packing dual-drive, USB 3.1 Gen 2 performance into a portable, bus-powered form factor, this is the perfect drive for high demand applications on the go. With ample capacities, no matter where you are, the Mercury Elite Pro Dual mini delivers the performance and flexibility to meet the most extreme workflow requirements for pros working with rich media content. Mercury Elite Pro Dual mini features easily user-selectable modes RAID 0 and RAID 1. Choose the configuration that suits your needs. In RAID 0, experience blistering data transfer speeds up to 989MB/s. Or select RAID 1 for greater data redundancy from mirrored disks. The Mercury Elite Pro Dual mini also features a rugged aluminum chassis designed for near silent fanless, cooling, which keeps your drives protected, cool and quiet everywhere you go. The slimline, side-by-side configuration means Mercury Elite Pro Dual mini fits easily in your laptop or gear bag, making it the perfect solution for your portable creative workflow.
FEATURES:
- 2.5″ SATA 6Gb/s support
- USB 3.1 Gen2
- RAID support for Redundancy or Performance
- Alluminum Chassis
- Includes extra cables and external power
SPECIFICATIONS:
- Interface: USB 3.1 Gen 2 / SATA RAID Controller (ASMedia ASM1352R)
- Drive support: 2.5″ SATA 6Gb/s drives, SATA revision 3.0/2.0 compatible
- Compressible Data: 633 MB/s Read and 738 MB/s Write
- Incompressible Data: 689 MB/s Read and 573 MB/s Write
- Random Read/Write (IOPS): 29K IOPS Read and 31K IOPS Write
- RAID Modes Supported: RAID 0, 1, SPAN, and Independent drive mode
- UASP (USB Attached SCSI Protocol) Compliant: Yes
- AC input: 100 ~ 240V, 50/60Hz
- DC output: 12V @ 3A
- Dimensions: 14.4 x 15.5 x 2.8 cm
- Weight: 600 g
WHAT’S IN THE BOX:
- OWC Mercury Elite Pro Dual Mini 2.5″ USB3.1|USB-C Enclosure – Silver x1
- USB Type-C to Type-C 50cm cable x1
- USB 3.1 Gen 1 Standard-A to Type-C 50cm cable x1
- External power supply and power cable x1
- Screw packet x1
- Quick Start Guide x1
| Weight | 1.06 kg |
|---|---|
| Dimensions | 26 × 8 × 20 cm |
| Software Requirements | OS (USB 3.1 Gen 1) OS X 10.7 or later Windows 7 or later Chrome OS OS (USB 3.1 Gen 2) macOS 10.12 or later and Thunderbolt 3 interface Windows 8.1 or later Chrome OS Driver Driver not required for OS X Driver not required for Windows Driver not required for Chrome |
| Hardware Requirements | Minimum Mac or PC with a USB 3.1 Gen 1 port (Standard-A or Type-C) Recommended (Best Performance) Mac or PC with a USB 3.1 Gen 2 Type-C port |
| Bootability | OS X 10.7 or later |
| Interface (Chipset) | (1) USB 3.1 Gen 2 / SATA RAID Controller (ASMedia ASM1352R) |
| UASP (USB Attached SCSI Protocol) Compliant | Yes |
| Drive(s) Supported | (2) 2.5″ SATA 6Gb/s drives (drive height up to 9.5mm) SATA revision 3.0 (6Gb/s) compliant Compatible with SATA revisions 2.0 (3Gb/s) and 1.0 (1.5Gb/s) |
| Performance | USB 3.1 Gen 2 Compressible Data: 633 MB/s Read and 738 MB/s Write Incompressible Data: 689 MB/s Read and 573 MB/s Write Random Read/Write (IOPS): 29K IOPS Read and 31K IOPS Write USB 3.1 Gen 1 Compressible Data: 437 MB/s Read and 431 MB/s Write Incompressible Data: 425 MB/s Read and 414 MB/s Write Note(s) Speeds will vary based on drives used, setup, and other factors. |
| RAID Modes Supported | Hardware RAID 0, 1, SPAN, and Independent drive mode |
| Initial Configuration | RAID 0 Included Drive Guide software will format the drive for either OS X or Windows |
| Power | Power Supply External UL-listed universal auto-switching AC input: 100 ~ 240V, 50/60Hz DC output:, 12V @ 3A Replacement power supply sold separately Adapter plugs for international use sold separately |
| Environment | Environmental (Operating) Temperature (°F) 32° – 107° Temperature (°C) 0° – 42° Environmental (Non-Operating) Temperature (°F) &min, 40° – 185° Temperature (°C) &min, 40° – 85° |
| Height | 28 mm (1.1 in) |
| Width | 155 mm (6.1 in) |
| Length | 144 mm (5.7 in |
| Weight (without drives) | 0.6 kg (1.25 lbs.) |
