Product Description
MikroTik Chateau 2.4 / 5 GHz Desktop LTE12 Access Point, 4 Core CPU, 256 MB RAM, Micro SIM, 16 MB Flash storage, 5x 1 GbE Ethernet ports, 2.4 GHz 802.11b/g/n dual-chain, 5 GHz 802.11a/n/ac dual-chain, LTE category 12, Option for external SMA conector, 600 Mbps LTE Maximum speed
Product Specifications
| Weight | 0.90 kg |
|---|---|
| Dimensions | 33.000000 × 16.000000 × 6.000000 cm |
| CPU | 4 core IPQ-4019 716 MHz |
| Size of RAM | 256 MB |
| Storage | 16 MB flash |
| Number of 1 GbE Ethernet ports | 5 |
| Wireless | 2.4 GHz 802.11b/g/n dual-chain, 5 GHz 802.11a/n/ac dual-chain |
| Wireless regulations | Specific frequency range will be limited by country regulations |
| Wireless antenna max gain | 2.5 dBi |
| LTE category | 12 (600 Mbps Downlink, 150 Mbps Uplink), the LTE chip is built-in, 4×4 MIMO LTE support |
| LTE antenna max gain | 4 dBi, option for external SMA conector |
| LTE bands | 1/3/5/7/8/20/28/38/40/41 |
| LTE max speed | 600 Mbps |
| LTE carrier aggregation | Yes |
| Antenna beam width | 360° |
| Supported input voltage | DC jack 12 – 28 V |
| Dimensions | 240 x 156 x 44 mm |
| Operating temperature | -40°C to +70°C |
| Operating system | RouterOS 7.0 (compatible only with v7 and above) |
| Micro SIM slots | 1 |
| USB port | 1 USB 2.0 port type A |
| Max power consumption | 23 W |
