Product Description
Features:
Nature Air Flow
The PC-Q27 has passive cooling design, due to less heat from the Mini-ITX system. There are vent at the bottom of the chassis, allow cool air coming in to cool the system down.
New side panel installation design
Just pushed up to release the side panel, and push down for closing.
HDD / SSD Space
The PC-Q27 hold up to three hard drives, a 3.5? HDD and a 2.5? SSD in the bottom and a 3.5? or 2.5? drive in the front.For even more storage capabilities,an addition 3.5? HDD can be installed in 5.25? drive bay.
Compatibility
- VGA Card length: 195mm
- PSU Space: 180mm
- CPU Sooler height: 70mm
Dual LED Power Switch
(Blue LED for Power on / Purple LED for HDD reading)
Product Specifications
| Model | PC-Q27 |
|---|---|
| Case Type | Mini Tower Chassis |
| Dimensions | (W) 200mm x (H) 300mm x (D) 240mm |
| Color | Black |
| Front bezel Material | Aluminum |
| Side Panel | Aluminum |
| Body Material | Aluminum |
| Net Weight | 2.1 kg |
| 5.25" drive bay (External) | 1 or 3.5-inch HDD x1 |
| 3.5" drive bay (External) | None |
| HDD bay | 3.5-inch HDD x3 ( Using one 5.25-inch space) / 2.5-inch HDD x2 ( Using one 3.5-inch space) |
| Expansion Slot | 1 |
| Motherboard | Mini-ITX |
| System Fan | None |
| I/O Ports | USB3.0 x 2 |
| Maximum Compatibility | VGA Card length: 195mm PSU length: 180mm CPU cooler height: 70mm |
| PSU | ATX PSU (Optional) |
| Package Dimensions | (W)263mm x (H)361mm x (D) 278mm |
| Gross Weight | 2.6kg |
