Product Description
Features:
Power Supply: VDD = 1.2V Typical
- VDDQ = 1.2V Typical
- VPP = 2.5V Typical
- VDDSPD = 2.2V to 3.6V
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Dual-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 16 internal banks; 4 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- PCB: Height 1.18″ (30.00mm)
- RoHS Compliant and Halogen-Free
Product Specifications
| SKU | KVR26S19D8/32 |
|---|---|
| Memory Capacity | 32GB |
| Model/Series/Type | ValueRAM |
| Brand | Kingston |
| CASLatency | CL19 |
| Chip Organization | x8 |
| Data Width | X64 |
| Form Factor | DDR4 |
| Memory Depth | 2G |
| Memory Voltage | 1.2v |
| Module Type | SODIMM |
| Operating Temperature | 0°C to 85°C |
| Pins | 260 Pin |
| Product Type/Family | RAM |
| RAM Memory Type | Non-ECC |
| Rank | 2R (Dual Rank) |
| Speed | 2666MHz (PC4-21300) |
