Product Description
Highlighted Features:
- Turn your laptop into a full-sized workstation through a single USB 3.0 cable
- Connect a keyboard, mouse, monitor, speakers, USB device, Gigabit Ethernet, etc.
- Multi-angle for notebook placement
- Dual HDMI/VGA individual display output
- Mac and Windows compatible
USB 3.0 SuperSpeed:
- Transfer rates of up to 5 Gbps, enable bulky file backup
- Hot-swapping connect and disconnect without powering down
- Two ports support fast charging BC V1.2 for smart phone, table and iPad charging up to 2A
Dual HDMI / VGA Display & Sound:
- Supports VGA & HDMI dual display resolutions up to 2048 x1152 @ 32 bit
- Supports 1080P video playback
- Supports display modes: primary, extended and mirror
- Display Rotation: 0, 90, 180 & 270 Degrees
- 3.5 mm audio in and out
- Supports audio output through an HDMI connection
USB 3.0 Gigabit Ethernet:
- Quickly add a Gigabit Ethernet port over USB 3.0
- USB 3.0 plug-and-play and backwards compatible with USB 2.0/1.1
- Transfer all of your files almost instantly over a true Gigabit network
- IEEE 802.3, 802.3u and 802.3ab (1BASE-T, 100BASE-TX, and 1000BASE-T) compatible
- Activity and link LED indicators
System Requirements:
- Microsoft Windows 10/ 8.1/ 8/ 7 (32-bit or 64-bit)
- Mac OS X 10.8 or later
- Available USB 3.1/3.0/2.0 port (USB 3.1/3.0 recommended)
- Office applications / Web
- CPU: Intel Core i3 Dual Core 2.8 GHz
- RAM: 2 GB memory or higher
- One 2K (2048 x 1152@60Hz) Full-screen video playback
- CPU: Intel Core i5 Quad Core
- RAM: 4 GB memory or higher
- Two 2K (2048 x 1152@60Hz) full-screen video playback
- CPU: Intel Core i7 Quad Core
- RAM: 8 GB memory or higher
- Graphics card: Intel HD Graphics 4000/ ATI HD 7xxx/ NVIDIA 5XXM or higher
Product Specifications
| Host Interface | USB 3.0 micro B connector |
|---|---|
| Cable | USB 3.0 micro B to type A |
| Video Interface | VGA-DB 15 pin female connector Standard HDMI female connector (includes audio) |
| USB Port | USB 3.0 female connector x 3 USB 3.0 battery charging V1.2 charging port x 2 (two ports, with the icon, provide additional power for up to 2A fast-charging an iPad, smart phones, tablet or similar products) |
| Audio Jack | Microphone: 3.5 mm stereo audio in Speaker: 3.5 mm stereo audio out |
| Power Adapter | Input: AC 100-240V, 50~60 Hz Output: DC 5V/3A (US/JP/TW) or 5V/4A (EU/UK/AU/CN) |
| Power Mode | Bus-powered & self-powered”3″ style=”bord |
| Display | Display resolution: 2048 x 1152 @ 32bit Display modes:primary, extended, mirror Display rotation: 0°, 90°, 180°, 270° |
| Ethernet | Transfer Rate: 1000 Mbps (Half Duplex) / 1000 Mbps (Full Duplex) IEEE: IEEE 802.3az, IEEE 802.3, 802.3u, and 802.3ab, IEEE 802.3x Modes: – Supports Wake on LAN function, suspend mode and remote wakeup via link-change, magic packet, or Microsoft wakeup frame – Supports IEEE 802.1Q VLAN tagging and 2 VLAN ID filtering – Supports Jumbo Frame – Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and TCP Large Send Offload |
| Dimensions | Main body: 301.1(W) x 28.5(H) x 22 (D) mm Cable length: 60 cm |
| Weight | Approximately 106.5g |
| Housing Material | Aluminum |
