In-Win ca03 D-Frame 2.0 White & Blue Open Frame E-ATX Chassis
R17,029.99 incl. VAT
Only 3 left in stock
Overview:
The design concept for D-Frame 2.0 originates from the freedom, individuality and impulsive nature of off-road motorcycles. The combination of steel tubing, anti-flip foot pads with deep tire treads, a power supply in the shape of an air-cooled engine and tempered glass is perfect fusion of art and technology.
Features:
Handcrafted Metallic Tubing Structure
Expertly bent tubing is entirely crafted by human hands. TIG (Tungsten Inert Gas) welding is used to reinforced stability, and unique electrode position, which creates an ultra-smooth finish! The motherboard mounting tray is sandblasted to achieve a refined metallic texture.
Innovative Two-Way Open Design with Quick-Release Fasteners
The outer frame features a unique two-way open design. With its quick-release fasteners, D-Frame 2.0 allows for easier assembling and custom display platforms.
Open-Frame Structure with Excellent Thermal Solutions
Open-frame structure improves heat dissipation and airflow is effectively channeled, ensuring excellent ventilated performance.
Highly Expandable for Superb Performance
Supports the latest high-end graphics cards, CPU heatsink and motherboards E-ATX (12”x13”).
USB 3.1 Type-C Ultra-High-Speed Transmission
Advanced USB 3.1 Type-C interface provides up to 10Gbps transmission speed*, greatly reducing data transmission time. Dual-side slot also increases convenience.
SIII-1065W Transparent Power Supply
Each D-Frame 2.0 includes a SIII-1065W power supply, which is exclusively designed for D-Frame 2.0
| Model | D-Frame 2.0 |
|---|---|
| Color | White/Blue |
| Case Type | Open-Air Chassis |
| Case Material | Reinforced Steel Tube, Aluminium, Tempered Glass |
| M/B Compatibility | 12″ x 13″ E-ATX, ATX, Micro-ATX |
| Expansion Slots | 8 x PCI-E Slots |
| Maximum Compatibility | VGA Card Length: 350-415mm (Depends on Mounting Configuration) VGA Card Height: 173mm (Motherboard Die Surface to Side Panel) CPU Heatsink Height: 165mm (CPU Die Surface to Side Panel) |
| Front Ports | 1 x USB 3.1 Type-C 3 x USB 3.0 HD Audio |
| Internal Drive Bays | 4 x 2.5“/3.5” Multifunctional Brackets |
| Thermal Solution Compatibility | 2 x 120mm Fan Brackets (Supports 2 x 120mm Fans) 1 x 3-in-1 Fan Bracket (Supports 3 x 120mm Fans) Supports 1 x 360mm Radiator – Front: 90mm Maximum Height Including Fan – Bottom: 65mm Maximum Height Including Fan |
| Power Supply Compatibility | SIII-1065W Internal PSU Included ATX12V and EPS12V – Dimension(L x W x H): 210 x 180 x 96 mm |
| Product Dimension (H x W x D) | 548 x 264 x 726 mm 21.6” x 10.4” x 28.6” |
| Product Dimension (H x W x D) with screw height | 548 x 291 x 726 mm 21.6″ x 11.5″ x 28.6″ |
| Package Dimension (H x W x D) | 760 x 346 x 842 mm 29.9″ x 13.6″ x 33.1″ |
| Net Weight | 22.5kg/49.5lbs |
| Gross Weight | 25.5kg/56.1lbs |
