Applications
- ? Live sound
- ? Rental
- ? Portable PA, clubs, ballrooms, live theatre
- ? House of worship
- ? Theme parks
- ? Music playback and sound reinforcement in small and mid-size venues
- ? Corporate A/V professionals and sound system hire companies
Features
- 1400 Watt Peak power – 700 Watt RMS
- 135 dB max SPL
- 55 Hz 20 kHz frequency?response
- 2 x 10? Woofers
- 1 x 3? Compression Driver
- DSP controlled Input section with selectable presets
- Tour grade safe and solid variable mechanics
- Composite PP enclosure structurally wooden reinforced
Acoustical Specifications
- Frequency Response -3 dB: 55 Hz ? 20 kHz
- Max SPL: 135 dB
- Horizontal coverage angle: 100?
- Vertical coverage angle: 15?
- Compression Driver: 2?, 3.0? v.c.
- Woofer: 2 x 10?, 2.5? v.c.
Input/Output Section
- Input signal: bal/unbal
- Input connectors: XLR
- Output connectors: XLR
- Input sensitivity: -2 dBu / 4 dBu
Processor Section
- Crossover frequencies: 800 Hz
- Protections: Thermal, RMS
- Limiter: Soft limiter
- Controls: Cluster, HF, High curving, Indoor
Amplifier Specifications
- Total power: 700 W
- High frequencies: 200 W
- Low frequencies: 500 W
- Cooling: Convection
- Connections: Powercon in/out
Cabinet
- Cabinet Material: Composite PP, wooden reinforced
- Hardware: Rigging flyware
- Handles: 2 side, 2 back
- Colour: Black
Physical Specifications
- Height: 294 / 11.5 mm/inch
- Width: 705 / 27.7 mm/inch
- Depth: 445 / 17.5 mm/inch
- Net Weight: 29 / 63.93 kg/lbs
