| Protocols/Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR- 069, SNMP, 802.1x, TLS, SRTP, IPv6 |
|---|
| Network Interfaces | Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE (GRP2601P only) |
|---|
| Graphic Display | 132 x 48 (2.21'') LCD display |
|---|
| Feature Keys | 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 8 dedicated function keys for: MESSAGE(with LED indicator), TRANSFER, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL- |
|---|
| Voice Codecs and Capabilities | Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723, iLBC, OPUS, in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC |
|---|
| Telephony Features | Hold, transfer, forward, 5-way conference, call park, call pickup, downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over |
|---|
| Auxiliary Ports | RJ9 headset jack (allowing EHS with Plantronics & Jabra &Sennheiser headsets) |
|---|
| Base Stand | Yes, 1 angle position available (45°), Wall Mountable (*wall mount sold separately) |
|---|
| QoS | Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS |
|---|
| Security | User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot |
|---|
| Multi-language | English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese, Russian, Croatian and more |
|---|
| Upgrade/Provisioning | Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR- 069 or AES encrypted XML configuration file |
|---|
| Power & Green Energy Efficiency | Universal Power Supply Input 100-240VAC 50-60Hz, Output +5VDC, 600mA, PoE: IEEE802.3af Class 1, 3.84W, IEEE802.3az (EEE) (GRP2601P Only) |
|---|
| Temperature and Humidity | Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing |
|---|
| Package Content | GRP2601/2601P phone, handset with cord, base stand, universal power supply (GRP2601 only), network cable, Quick Installation Guide |
|---|
| Physical | Dimension: 208mm (L) x 180mm (W) x 63.4mm (H) (with handset)
Unit weight:650g, Package weight:810g (860g for GRP2601) |
|---|
| Compliance | FCC: Part 15 Class B, FCC Part 68 HAC, CE: EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 62368-1, RCM: AS/NZS CISPR32, AS/NZS 62368.1, AS/CA S004, IC: ICES-003, CS-03 |
|---|
|
