Telephony standards | DECT |
---|
Frequency bands | 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US)
1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea)
1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan) |
---|
Number of Channels | 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan) |
---|
Range | up to 300 meters outdoors and 50 meters indoors |
---|
Peripherals | Power, Network, Register, Call, DECT |
---|
5 LED indicators | Reset button, Pairing/Paging button
One 10/100 Mbps auto-sensing Ethernet port with integrated PoE |
---|
Protocol/Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR)
DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
(Pending)
Voice Codecs G.711?/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS, G.722.2/AMR-WB (special order)
in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, CNG, PLC, AJB |
---|
Telephony Features | Hold, transfer, forward, 3-way conference, downloadable phonebook (XML, LDAP, up to 3000
entries), call waiting, call log (up to 300 records), auto answer, flexible dial plan, music on hold
server redundancy and fail-over
Sample Applications Weather, Currency (Pending)
QoS Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS) |
---|
Security | User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES
encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control, DECT authentication
& encryption |
---|
Multi-language | Arabic, Chinese Simple, Chinese Tradition, Croatian, Czech, Danish, Dutch, English, Estonian
Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish
Portuguese, Romanian, Russian, Slovenian, Spanish, Swedish, Turkish
Upgrade/ Provisioning Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or AES encrypted XML
configuration file
Multiple SIP Accounts
Up to ten (10) distinct SIP accounts per system
Each handset may map to any SIP account(s)
Each SIP account may map to any handset(s)
Ring Group
Flexible options when multiple handsets share the same SIP account |
---|
Circular Mode | all phones ring sequentially from the phone next to the one that answered last |
---|
Linear Mode | all phones ring sequentially in the predesignated order |
---|
Parallel Mode | all phones ring concurrently and after one phone answers, the remaining
available phones can make new calls |
---|
Shared Mode | all phones ring concurrently and always share the same line similar to analog
phones |
---|
Power & Green Energy Efficiency | Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection; |
---|
PoE | IEEE802.3af Class 1, 0.44W–3.84W |
---|
Package Content | Base Unit, Universal Power Supply; Ethernet cable; Quick Start Guide
Dimensions (H x W x D) 28.5 x 130 x 90 mm |
---|
Weight Base unit | 143g; Universal Power Supply: 50g; Package: 360g |
---|
Temperature and Humidity Operation | -10 to 55ºC (41 to 131ºF); Storage: -20º to 60ºC (-4 to 140ºF) |
---|
Humidity | 10% to 90% non-condensing |
---|
FCC | Part 15D, 47 CFR 2.1093, Part 15B |
---|
CE | EN60950, EN301489-1-6, EN301406, EN50566 |
---|
RCM | AS/NZS60950 (Pending) |
---|
Weight | 0.38 kg |
---|
Dimensions | 20.000000 × 16.000000 × 8.000000 cm |
---|
|
