Product Description
240 Watts 4 Ohms
1″ Aluminum Voice Coil
SPECIFICATIONS
Nominal Diameter 3.78 / 96mm
Nominal Impedance 4 ohm
AES Power Handling 60W
Program Power Handling 120W
Peak Power Handling 240W
Sensitivity (1w/1m) 103.5 dB
Frequency Response 3.5-20KHz
Recommended Hi Pass Crossover 3.5KHz Pair
MOTOR Voice Coil Diameter 1 / 25.4 mm VC Former Material Kapton Winding Material CCAW Diaphragm Material Aluminum Magnet Material Ferrite Magnet Weight 8 oz Body Material Aluminum Bullet Material Aluminum MEASUREMENTS Overall Diameter 3.78 / 96mm Overall Depth 2.78 / 70.5mm Front Mount Baffle Cutout 2.83 / 72mm Mounting Depth 2.56 / 65mm Motor Diameter 2.76 / 70mm
1″ Aluminum Voice Coil
SPECIFICATIONS
Nominal Diameter 3.78 / 96mm
Nominal Impedance 4 ohm
AES Power Handling 60W
Program Power Handling 120W
Peak Power Handling 240W
Sensitivity (1w/1m) 103.5 dB
Frequency Response 3.5-20KHz
Recommended Hi Pass Crossover 3.5KHz Pair
MOTOR Voice Coil Diameter 1 / 25.4 mm VC Former Material Kapton Winding Material CCAW Diaphragm Material Aluminum Magnet Material Ferrite Magnet Weight 8 oz Body Material Aluminum Bullet Material Aluminum MEASUREMENTS Overall Diameter 3.78 / 96mm Overall Depth 2.78 / 70.5mm Front Mount Baffle Cutout 2.83 / 72mm Mounting Depth 2.56 / 65mm Motor Diameter 2.76 / 70mm
