Avlink – Ad-Aud14 4 Way Stereo Distribution Amplifier

A very compact stereo audio distribution amplifier which supports 1 input to 4 outputs. Ideal for distributing the audio signal from a stereo source to 4 amplifiers/active speakers without any signal loss.

FEATURES:

• 1 x stereo input to 4 x stereo outputs
• Gold plated RCA phono sockets for optimum signal transfer
• Power switch with an integral LED
• Compact metal case with non-slip feet
• Supplied with a 2m, 2 x RCA to 2 x RCA connecting lead

SPECIFICATIONS:

• Power supply:
  12Vdc, 420mA
• Audio input:
  1 x Stereo (L&R), 47k ohms
• Audio output:
  4 x Stereo (L&R), 47k ohms
• Frequency response:
  20Hz – 20kHz, +0.1dB max.
• Signal to noise ratio:
  95dB min.
• Dimensions:
  176 x 90 x 26mm
• Weight:
  380g
