Images & Specifications Are For Illustrative Purposes Only & May Differ From The Actual Product. E&OE
Features:
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD display
Alpha-Numeric Display which displays system parameters and alarms.
Serial connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Network manageable
Provides remote power management of the UPS over the network.
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
Serial connectivity
Provides management of the UPS via a serial port.
SmartSlot
Customize UPS capabilities with management cards.
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Management Software
Allows the user to manage the UPS functions, schedule automatic shutdown and monitor the power grid occurrences through an interactive interface that ensures an easy and intuitive monitoring.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
USB connection
Use your PC to access additional power protection and management features for your UPS via a USB Port.
Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Predicitive failure notification
Provides early-warning fault analysis ensuring proactive component replacement.
High efficiency
High efficiency rates that remain stable even at lower operating power levels
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
SmartSlot
Customize UPS capabilities with management cards.
Management Software
Allows you to easily monitor your utility power and manage your UPS.
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Double conversion on-line topology
Guarantees a consistently high level of power quality. Any disturbances on the distribution waveform are regenerated via the zero transfer time AC to DC then DC to AC conversion process. The battery is only used as a back-up source.
Intuitive LCD interface
Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
Wide input voltage range
Designed for harsh electrical environments to save battery life.
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
| Output power capacity | 800Watts / 1.0 kVA |
|---|---|
| Max Configurable Power (Watts) | 800Watts / 1.0 kVA |
| Nominal Output Voltage | 230V |
| Output Voltage Distortion | 0,03 |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Output Voltages | 220, 240 |
| Load Crest Factor | 3 :: 1 |
| Topology | Double Conversion Online |
| Waveform type | Sine wave |
| Output Connections | (3) IEC 320 C13 (Battery Backup) |
| Nominal Input Voltage | 230V |
| Input frequency | 40 – 70 Hz |
| Input Connections | IEC-320 C14 |
| Input voltage range for main operations | 160 – 280V |
| Number of Power Cords | 1 |
| Other Input Voltages | 220, 240 |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time | 4hour(s) |
| Interface Port(s) | USB |
| Control panel | Multi-function LCD status and control console |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Surge energy rating | 600Joules |
| Maximum Height | 223mm, 22.3CM |
| Maximum Width | 145mm, 14.5CM |
| Maximum Depth | 288mm, 28.8CM |
| Net Weight | 9.3KG |
| Shipping weight | 10.6KG |
| Shipping Height | 330mm, 33.0CM |
| Shipping Width | 235mm, 23.5CM |
| Shipping Depth | 365mm, 36.5CM |
| Operating Temperature | 0 – 40 °C |
| Operating Relative Humidity | 0 – 95 (non-condensing) % |
| Operating Elevation | 0-3000meters |
| Storage Temperature | -20 – 50 °C |
| Storage Relative Humidity | 0 – 95 (non-condensing) % |
| Storage Elevation | 0-14763.6meters |
| Approvals | CE, IEC 62040-1-1, IEC 62040-1-2 |
