Features:
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
Dataline surge protection
Provides protection of connected equipment from power surges on the data lines.
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
PowerChute Personal Edition OS Compatibility
This software supports numerous operating systems and processors.
Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
LED status display
Quickly understand unit and power status with visual indicators.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
Surge only outlets
Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
| Max Configurable Power (Watts) | 410 Watts / 750VA |
|---|---|
| Output Frequency (sync to mains) | 50/60 Hz +/- 1 Hz Sync to mains |
| Topology | Line interactive |
| Waveform type | Stepped approximation to a sinewave |
| Transfer Time | 6 ms typical : 10 ms maximum |
| Input frequency | 50/60 Hz +/- 5 Hz Auto-sensing |
| Input voltage range for main operations | 140 – 300V |
| Number of Power Cords | 1 |
| Input Power Factor at Full Load | 0,63 |
| Battery type | Lead-acid battery |
| Typical recharge time | 8hour(s) |
| Expected Battery Life (years) | 03-Feb |
| Interface Port(s) | USB |
| Control panel | LED Status display with on line : on battery |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm |
| Surge energy rating | 273Joules |
| Data Line Protection | RJ45 10/100/1000 Base-T Ethernet protection |
| Maximum Height | 160MM, 16.0CM |
| Maximum Width | 120MM, 12.0CM |
| Maximum Depth | 355MM, 35.5CM |
| Net Weight | 5.4KG |
| Shipping weight | 5.9KG |
| Shipping Height | 250MM, 25.0CM |
| Shipping Width | 197MM, 19.7CM |
| Shipping Depth | 430MM, 43.0CM |
| Color | Black |
| SCC Codes | 1,07313E+13 |
| Operating Temperature | 0 – 40 °C |
| Operating Relative Humidity | 0 – 95 (Non-condensing) % |
| Operating Elevation | 0 – 3000meters |
| Storage Temperature | -15 – 40 °C |
| Storage Relative Humidity | 0 – 95 (Non-condensing) % |
| Storage Elevation | 0 – 3000meters |
| Audible noise at 1 meter from surface of unit | 40.0dBA |
| Protection Class | IP20 |
| Approvals | CB, CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2 |
| Equipment protection policy | Lifetime : 50000 euros |
