5-channel 19? rack-mountable mixer-amplifier, tailored to commercial sound installations to power 100V line speakers or standard speakers down to a 4 Ohm load. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line. Features an inbuilt DAB+/FM radio tuner, front-mounted SD/USB ports, and Bluetooth® connectivity, all controlled via an integrated media player for hassle-free playback. A switchable voiceover feature automatically lowers the background music volume when a signal is detected via mic input 1 and rear panel 24V contacts can mute all except mic input 1 when triggered. Outputs on screw terminal are via 4 switchable zones with a separate always on output for priority alert speakers.
170-264Vac, 50Hz (IEC)
DC power:
24Vdc (screw terminals)
Inputs:
Mic XLR, 2 x mic/line jack, 2 x RCA line
Input sensitivity : mic 1:
(balanced)-53dBV
Input impedance : mic:
15k Ohms
Input sensitivity : line:
(unbalanced)-15dBV (-18.5dBV line 5)
Input impedance : inputs:
2-51k Ohms
Line output:
RCA
Speaker outputs:
4 switched + 1 non-switched 100V / 4-16 Ohms / COM
Controls:
Mic1, mic/line2+3, line4+5, bass, treble, master volume
Equaliser : bass:
100Hz ±10dB
Equaliser : treble:
10kHz ±10dB
Rear panel switches:
Phantom, Vox, Mic/Line (2 + 3)
Phantom power:
+20V (mic 1 XLR, switchable)
Audio source:
DAB+/FM tuner, USB/SD player, Bluetooth receiver
Emergency control:
24V contacts – mute all except Mic.1 when triggered
Bluetooth version:
5.0
THD:
<1.0%
Output power : rms:
360W
Fuse :
T5A
Dimensions :
433 x 410 x 88mm
Weight:
9.14kg
