Outdoor Wi-Fi 6 Dual-Band Gigabit Wall Mount Access Point
R4,413.50 incl. VAT
Only 1 left in stock
RG-RAP6260(G) is one of the wireless products fully developed by Ruijie Reyee. The device supports 802.3at PoE In power supply. With concurrent 2.4GHz and 5GHz, the AP supports dual-band dual-stream MIMO technology, providing 574Mbps at 2.4G, and 1201Mbps at 5G.
RG-RAP6260(G) applies for IP68 protection on the outer shell design, which is suitable in the outdoor environment and voids the influence from the extreme condition. The device meets the demanding requirements, such as able to perform under ultra-cold and humid weather. This reduces the difficulty of installation and maintenance. RG-RAP6260(G) supports Power over Ethernet remote mode, which is highly suitable for many scenarios such as education, government, medical, finance, business.
| Technical Specification | Specification Description |
|---|---|
| Model | RG-RAP6260(G) |
| Radio | Dual-stream dual-band |
| Protocol | Concurrent 802.11a/b/g/n/ac/ax |
| Operating Bands | 802.11b/g/n/ac/ax 2.4G ~ 2.4835GHz 802.11a/n/ac/ax 5G 5.150 5.35GHz / 5.725. (country specific) |
| Antenna | Internal antennas (2.4GHz: 4dBi 5GHz: 6dBi) |
| Spatial Streams | 2.4 GHz 2×2 MU-MIMO 5 GHz 2×2 MU-MIMO |
| Max Throughput | Up to 575Mbps at 2.4GHz Up to 1200Mbps at 5GHz Totally 1775Mbps per AP |
| Modulation | DBPSK/DQPSK/CCK(DSSS)/BPSK/QPSK/16QAM/64QAM/256QAM/1024QAM |
| Receive Sensitivity | 11b-91dBm(1Mbps)-88dBm(5Mbps)-85dBm(11Mbps) 11a/g 89dBm 6Mbps-80dBm 24Mbps-76dBm 36Mbps-71dBm 54Mbps 11n-83dBm@MCS0-65dBm@MCS7-83dBm@MCS8-65dBm@MCS15 11ac HT20-83dBm MCS0, -57dBm MCS9 11ac HT40-79dBm MCS0, -57dBm MCS9 11ac HT80-76dBm MCS0, -51dBm MCS9 11ax HE80 -82dBm MCS, -57dBm MCS9 ,-52dBm MCS11 |
Maximum Output Power of the Transmitter (Single Stream) | 2.4GHz(2.4~2.4835GHz) 26dBm 5GHz(5.150~5.250GHz,5.725~5.850GHz) 25dBm country-specific comply with local laws |
| Adjustable Power | 1dBm |
| Dimensions | 298mm298mm65mm (excluding mounting kits) |
| Weight | 1.35kg (excluding mounting kits) |
| Service Ports | 1 10/100/1000 Base-T Ethernet port supports PoE IN 1 100/1000 Base-X SFP Port |
| Management Port | N/A |
| LED Indicator | Single indicator (Blue light) |
| Power Supply | 802.3at PoE (Warning 802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie POE+ switch or 802.3at POE adapter as power supplier) |
| Power Consumption | 17W |
| Bluetooth | Support |
| Environment | Operating Temperature -40°C 65°C |
| Storage Temperature -40°C 5°C | |
| Operating humidity 0% 100%, non-condensing | |
| Storage humidity 0% 100% condensing/non-condensing | |
| Installation | Ceiling/Wall-Mountable |
| Safety Standard | GB4943 IEC 60950-1 |
| EMC Standard | GB9254 EN301 489 EN50155 EN50121 |
| Vibration Standard | IEC61373 |
| Radio Standard | EN300 328 EN301 893 |
| MTBF | >400000H |
| WLAN | Maximum number of clients: 512 |
| Recommended number of clients: 100 | |
| Up to 8 SSID | |
| Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID | |
| SSID-based and radio-based STA limit | |
| Support Layer 2 user isolation | |
| Roaming | Support layer 2 and layer 3 roaming |
| Security | Support PSK authentication |
| Support static blacklist and whitelist | |
| Support WPA TKIP,WPA2 AES,WPA-PSK data encryption | |
| Routing | Support static IP address, DHCP, PPPoE Dial |
| Management and Maintenance | Support unified networking of all network equipment Support local or remote management with Ruijie Cloud APP Support local management with web Support remote management with Ruijie Noc Cloud platform |
| Platform Management Features | Automatic RF adjustment via the platform |
| Unified configuration via the platform | |
Unified monitoring via the platform |
| Weight | 2 kg |
|---|---|
| Dimensions | 41 × 41 × 18 cm |
