| Hardware Specifications |
| Hardware Version | 2 |
| Copper Ports | 16 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| SFP/mini-GBIC Slots | 2 100/1000BASE-X SFP interfaces, supporting 100/1000Mbps dual mode |
| Console | 1 x RS232-to-RJ45 serial port (115200, 8, N, 1) |
| Reset Button | System factory default |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 36Gbps/non-blocking |
| Switch Throughput@64 bytes | 26.7Mpps @64 bytes |
| MAC Address Table | 8K entries |
| Shared Data Buffer | 4.1 megabits |
| Flow Control | IEEE 802.3x pause frame for full-duplex |
| Back pressure for half-duplex |
| Jumbo Frame | 9216 bytes |
| Reset Button | > 5 sec: Factory default |
| LED | System: |
| Power (Green) |
| 10/100/1000T RJ45 Interfaces (Port 1 to Port 16): |
| 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange) |
| 100/1000Mbps SFP Interfaces (Port 17 to Port 18): |
| 1000 LNK/ACT (Green), 100 LNK/ACT (Orange) |
| Power Requirements | 100~240V AC, 50/60Hz, 0.8A (max.) |
| Power Consumption/Dissipation | Max. 10.4 watts/35 BTU |
| Dimensions (W x D x H) | 445 x 207 x 45 mm (1U height) |
| Weight | 2kg |
| ESD Protection | Yes |
| Enclosure | Metal |
| Layer 2 Functions |
| Port Mirroring | TX/RX/both |
| Many-to-1 monitor |
| VLAN | 802.1Q tagged-based VLAN |
| Up to 256 VLAN groups, out of 4094 VLAN IDs |
| 802.1ad Q-in-Q tunneling (VLAN stacking) |
| Voice VLAN |
| Protocol VLAN |
| Private VLAN (Protected port) |
| GVRP |
| Management VLAN |
| Link Aggregation | IEEE 802.3ad LACP and static trunk |
| Supports 8 groups of 8-port trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) |
| IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) |
| IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) |
| STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IPv4 IGMP (v2/v3) snooping |
| IGMP querier |
| Up to 256 multicast groups |
| MLD Snooping | IPv6 MLD (v1/v2) snooping, up to 256 multicast groups |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL |
| IPv4/IPv6 IP-based ACE/MAC-based ACE |
| QoS | 8 mapping IDs to 8 level priority queues |
| – Port number |
| – 802.1p priority |
| – DSCP/IP precedence of IPv4/IPv6 packets |
| Traffic classification based, strict priority and WRR |
| Ingress/Egress Rate Limit per port bandwidth control |
| Security | IEEE 802.1X port-based authentication |
| Built-in RADIUS client to co-operate with RADIUS server |
| RADIUS/TACACS+ authentication |
| IP-MAC port binding |
| MAC filtering |
| Static MAC address |
| DHCP snooping and DHCP Option82 |
| STP BPDU guard, BPDU filtering and BPDU forwarding |
| DoS attack prevention |
| ARP inspection |
| IP source guard |
| Storm control support |
| Broadcast/unknown unicast/unknown multicast |
| Management Functions |
| Basic Management Interfaces | RJ45 Console; Web browser; Telnet; SNMP v1, v2c, v3 |
| Firmware upgrade by HTTP/TFTP protocol through Ethernet network |
| Configuration upload/download through HTTP/TFTP |
| Remote/Local Syslog |
| System log |
| LLDP Protocol |
| SNTP |
| PLANET Smart Discovery Utility |
| Secure Management Interfaces | HTTPs, SNMP v3 |
| SNMP MIBs | RFC 3635 Ethernet-like MIB |
| RFC 2863 Interface Group MIB |
| RFC 2819 RMON (1, 2, 3, 9) |
| RFC 1493 Bridge MIB |
| Standards Conformance |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX/100BASE-FX |
| IEEE 802.3z Gigabit SX/LX |
| IEEE 802.3ab Gigabit 1000BASE-T |
| IEEE 802.3x flow control and back pressure |
| IEEE 802.3ad port trunk with LACP |
| IEEE 802.1D Spanning Tree Protocol |
| IEEE 802.1w Rapid Spanning Tree Protocol |
| IEEE 802.1s Multiple Spanning Tree Protocol |
| IEEE 802.1p Class of Service |
| IEEE 802.1Q VLAN Tagging |
| IEEE 802.1x Port Authentication Network Control |
| IEEE 802.1ab LLDP |
| RFC 768 UDP |
| RFC 793 TFTP |
| RFC 791 IP |
| RFC 792 ICMP |
| RFC 2068 HTTP |
| RFC 1112 IGMP version 1 |
| RFC 2236 IGMP version 2 |
| RFC 3376 IGMP version 3 |
| RFC 2710 MLD version 1 |
| RFC 3810 MLD version 2 |
| Environment |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) |
