ASUS Dual-Band ZenWiFi XD5 (Single-Pack) Home Mesh WiFi System – White
KEY FEATURES:
– WiFi 6 Dual-Band Router Mesh Node – 1 Pack
– ASUS AiMesh Compatible
– WPA3 Capable Security
– 2x Internal Antennas with MU-MIMO Technology
– Supports Universal Beamforming
– 2.4GHz Bandwidth: Up to 574Mbps
– 5.0GHz Bandwidth: Up to 2402Mbps
– 1x Gigabit Ethernet RJ-45 LAN/WAN Port
– 1x Gigabit Ethernet RJ-45 LAN Port
– ASUS AiProtection Classic Network Security
– ASUSWRT Dashboard
– ASUS Router App Support
– 3 Year Warranty
Description
ASUS Dual-Band ZenWiFi XD5 (Single-Pack) Home Mesh WiFi System – White
90IG0750-MO3B60
ASUS ZenWifi XD5
WiFi Coverage Everywhere. Always Secure.
The ZenWiFi XD5 system consists of three ASUS AX3000 WiFi 6 router, featuring unique technologies that give you superfast, reliable and secure WiFi connections — inside or outside your home!
Features
ZenWiFi XD5 puts your WiFi into top gear! With a total bandwidth of up to of 3000 Mbps, it’s up to 3X faster* than WiFi 5 routerExplore ultimate WiFi 6 performance
The ASUS ZenWiFi XD5 supports high-speed 160MHz bandwidth*. It dramatically increases network capacity while reducing congestion, delivering higher performance for every WiFi 6 device.Flexible Network Naming
Uniquely, ZenWiFi lets you choose how you name your WiFi networks: a single name for everything, or separate names for each frequency band. The choice is yours!Easier-than-ever Setup
- Turn on ZenWiFi XD5
- Create a WiFi network name and an admin account
- Wait for 3 minutes, and you’re done!
What makes ZenWiFi XD5 setup so easy?
- One-time setup, with auto synchronization for all the hubs in each package
- Use a network cable to connect your modem to the WAN port of one XD5. This ZenWiFi XD5 will be the AiMesh router, and the other two ZenWiFi XD5 will be the AiMesh nodes
Make the Internet a Safer Place for Everyone
AiProtection Classic with Parental Controls is free for life. It gives you total peace of mind, and you can keep an eye on everything that’s happening on your network via the mobile app.
- Commercial Grade Security
- Parental Controls
- No Subscription Fee
Some routers only offer 3 years of protection, ASUS AiProtection has you covered for the life of your product.
- No Subscription Fee
- 24/7 Auto Update
ZenWiFi keeps your network running securely with automatic firmware updates and is always in sync with Trend Micro’s cloud database, so you can always enjoy the best Internet experience.
- 24/7 Auto Update
- Block Access to Malicious Websites
AiProtection uses Trend Micro’s official database to identify and block known malicious sites, preventing infection even before you click.
- Block Access to Malicious Websites
- Infection Detection and Blocking
Even if an already-infected device is connected to ZenWiFi, AiProtection prevents any personal data on the device from being compromised.
- Infection Detection and Blocking
Parental Controls
URL filter and scheduling allow you to protect your family from unhealthy Internet usage behavior.
Smart Looks for Smart Homes
ZenWiFi XD5 works perfectly with smart-home services — including Alexa skills — and is available in charcoal or white to suit your décor.
Space-saving and Great Design
Comes with mounting holes and a screw pack. Hang it on the wall or place it anywhere, the choice is yours!
AiMesh Technology Easy setup. Flexible management.
Even non-experts can quickly set up AiMesh technology, while more experienced users will appreciate the comprehensive advanced networking features.
Additional Information:
Specifications
| Make and Model | ASUS ZenWifi XD5 1 Pack Router |
|---|---|
| Part Number | XD5 (W-1PK) |
| Color | White |
| Product Segment | AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps |
| AX technology | Yes |
| Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
| Antenna | Internal dual-band antenna x 2 |
| Transmit/Receive | 2.4GHz 2×2 5GHz 2×2 |
| Boosts speed | MIMO technology |
| Operating Frequency | 2.4 G Hz / 5 GHz |
| Ports | RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1 |
| Button | WPS Button, Reset Button |
| LED Indicator | Power x 1 |
| Power Supply | “AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 1.5 A current” |
| AiMesh | AiMesh Primary AiMesh router AiMesh node |
| Router APP | ASUS Router APP |
| Alexa | Support Alexa skill |
| AiProtection | AiProtection Classic Malicious site blocking Infected Device Prevention and Blocking |
| Parental Control | Parental Control Parental Control Customized Internet schedule |
| Traffic Control | Bandwidth Monitor Bandwidth limiter Traditional QoS Real-time traffic monitor Wired Traffic Monitor Wireless Traffic Monitor |
| Wireless | IPv6 Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support UTF-8 SSID Guest Network Guest Network Connection time limit WPS |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Android tethering Port forwarding Port triggering DMZ DDNS NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP Let’s Encrypt |
| LAN | DHCP Server IGMP snooping IPTV Manually assign IP address |
| VPN | VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP |
| Administration | Operating system : ASUSWRT Free OS upgrade Firewall Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 Wake on LAN (WOL) SSH Configuration backup and restore Diagnosis tools Feedback system System log |
| Dimensions | N/A |
| Weight | N/A |
Package Contents
- ASUS XD5 Mesh Router
- RJ45 Ethernet cable
- Power adapter
- Quick start guide
- Warranty Card
- Screw Pack
