Features:
Availability
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Manageability
Network manageable
Provides remote power management of the UPS over the network.
Audible alarms
Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
LED status indicators
Quickly understand unit and power status with visual indicators.
Serial connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Serviceability
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to repair (MTTR)
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Predictive failure notification
Provides early-warning fault analysis ensuring proactive component replacement.
Resettable circuit breakers
Enables a quick recovery from overload events.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Adaptability
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Safety
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
| Output Power Capacity | 2700 Watts / 3000 VA |
|---|---|
| Max Configurable Power | 2700 Watts / 3000 VA |
| Nominal Output Voltage | 230V |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Output Voltages | 208, 220, 240 |
| Crest Factor | 03:01 |
| Topology | Line Interactive |
| Waveform Type | Sine wave |
| Output Connections | (8) IEC 320 C13 (2) IEC 320 C19 (2) IEC Jumpers |
| Nominal Input Voltage | 208V, 230V |
| Input Frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections | IEC-320 C20 |
| Schuko CEE 7 / EU1-16P | British BS1363A |
| Cord Length | 1.83 meters |
| Input voltage range for main operations | 140 – 280V |
| Other Input Voltages | 220, 240 |
| Transfer Time | 2-4 ms |
| Battery Type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time | 3 hour(s) |
| Replacement Battery | APCRBC143 |
| RBC Quantity | 1 |
| Extended Run Options | APC Smart-UPS X 3000VA Rack/Tower LCD 200-240V |
| Interface Port(s) | SmartSlot |
| Available SmartSlot Interface Quantity | 1 |
| Control panel | LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control console |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Emergency Power Off (EPO) | Yes |
| Surge energy rating | 645 Joules |
| Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Data Line Protection | — |
| Maximum Height | 432.00 mm |
| Maximum Width | 178.00 mm |
| Maximum Depth | 483.00 mm |
| Rack Height | 4U |
| Net Weight | 38.64 KG |
| Shipping Weight | 47.73 KG |
| Shipping Height | 330.00 mm |
| Shipping Width | 586.00 mm |
| Shipping Depth | 633.00 mm |
| Color | Black |
| Operating Environment | 0 – 40 °C |
| Operating Relative Humidity | 0 – 95% |
| Operating Elevation | 0-3000 meters |
| Storage Temperature | -15 – 45 °C |
| Storage Relative Humidity | 0 – 95% |
| Storage Elevation | 0-15000 meters |
| Audible noise at 1 meter from surface of unit | 55.00 dBA |
| Online Thermal Dissipation | 184.00 BTU/hr |
| Regulatory Approvals | C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE |
| RoHS | Compliant |
| REACH | REACH: Contains No SVHCs |
