Product Description
Share This Product On:
Features:
Availability
- Automatic internal bypass: Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
- Scalable runtime: Allows additional run time to be quickly added as needed.
- Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
- Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.
Manageability
- Network manageable: Provides remote management of the UPS over the network.
- InfraStruXure Manager Compatible: Enables centralized management via the APC InfraStruXure Manager.
- SmartSlot: Customize UPS capabilities with management cards.
- LED status indicators: Quickly understand unit and power status with visual indicators.
- Serial Connectivity: Provides management of the UPS via a serial port.
Adaptability
- Plug-and-Play external batteries: Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
- Rack/Tower convertible: Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
- Flash upgradeable firmware: Install maintenance releases of firmware remotely using FTP.
Serviceability
- User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Predicitive failure notification: Provides early-warning fault analysis ensuring proactive component replacement.
- Disconnected battery notification: Warns when a battery is not available to provide backup power.
- Audible alarms: Provides notification of changing utility power and UPS conditions
Protection
- Frequency and voltage regulation: Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
- Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Input power factor correction: Minimizes installation costs by enabling the use of smaller generators and cabling.
- Generator compatible: Ensures clean, uninterrupted power to protected equipment when generator power is used.
- Cold-start capable: Provides temporary battery power when the utility power is out.
- Resettable circuit breaker: Easy recovery from overloads; no need to replace a fuse.
- Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Product Specifications
| Output Power Capacity | 2100 Watts / 3000 VA |
|---|---|
| Max Configurable Power | 100 Watts / 3000 VA |
| Nominal Output Voltage | 230V |
| Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
| Output Voltage Distortion | Less than 3% |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 |
| Other Output Voltages | 220, 240 |
| Crest Factor | 3 : 1 |
| Topology | Double Conversion Online |
| Waveform Type | Sine wave |
| Output Connections | (8) IEC 320 C13; (2) IEC 320 C19; (2) IEC Jumpers |
| Bypass | Internal Bypass (Automatic and Manual) |
| Nominal Input Voltage | 230V |
| Input Frequency | 50/60 Hz +/- 5 Hz (auto sensing) |
| Input Connections | British BS1363A; IEC-320 C20; Schuko CEE 7/EU1-16P |
| Cord Length | 2.44 meters |
| Input voltage range for main operations | 160 – 280V |
| Input voltage adjustable range for mains operation | 100 – 280V |
| Other Input Voltages | 220, 240 |
| Battery Type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Included Battery Modules | 2 |
| Typical recharge time | 2.50 hour(s) |
| Replacement Battery | RBC44 |
| RBC Quantity | 1 |
| Extended Run Options | APC Smart-UPS RT 3000VA 230V |
| Interface Port(s) | RJ-45 Serial, Smart-Slot |
| Available SmartSlot Interface Quantity | 1 |
| Control panel | LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Emergency Power Off (EPO) | Yes |
| Surge energy rating | 480 Joules |
| Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Maximum Height | 432.00 mm |
| Maximum Width | 130.00 mm |
| Maximum Depth | 660.00 mm |
| Rack Height | 3U |
| Net Weight | 54.55 KG |
| Shipping Weight | 63.64 KG |
| Shipping Height | 347.00 mm |
| Shipping Width | 603.00 mm |
| Shipping Depth | 980.00 mm |
| Color | Black |
| Operating Environment | 0 – 40 °C |
| Operating Relative Humidity | 0 – 95% |
| Operating Elevation | 0-3000 meters |
| Storage Temperature | -15 – 45 °C |
| Storage Relative Humidity | 0 – 95% |
